Name: Major Tech MTC50 2-In-1 LAN Tester and Multimeter
SKU: 801797

CAT III 300V and CAT II 600V
2-in-1 LAN Tester and Digital Multimeter
LED displays the actual pin configuration and tests the correct pin configuration of 100Base-T, 10Base-T, 10Base-2 Thin Ethernet cable, RJ45/RJ11 modular cables 356A, TIA-568A/568B and Token Ring cable etc
With remote kit it can remotely test cables up to 300m away either on wall plate or patch panel
Can test the grounding
Provides easy to read continuity and fault status display
Measures ACV and DCV up to 600V, ACA and DCA up to 200mA
Locked Status wiring function
LAN Testing
Tests CAT 5 Installations

The MTC50 is a 2-in-1 LAN tester as well as an auto ranging multimeter. This meter is a newly designed and very practical tester that can easily read the correct pin configuration of 10/100 Base-T cable (Category 5), 10Base-2 cable (coax), RJ45/RJ11 modular cables, AT&T 258A, 356A, TIA-568A/568B and Token Ring cable by comparing one transmitting end to the corresponding receiving end. With the remote kit test cables can be installed over long distances either on wall plates or patch panels. It is easy to verify the cable continuity, open, short and cross-connect. The auto range digital multimeter allows the user to measure AC and DC voltage, AC and DC current, Resistance, Continuity and Diode test.

Specifications

Function	Range	Resolution	Accuracy
DC Voltage	200mV – 600V	0.1mV	±(1.0% 3 Digits)
AC Voltage	200mV – 600V	1mV	±(1.0% 5 Digits)
DC Current	200.0μ A – 200.0mA	0.1μA	±(1.5% 3 Digits)
AC Current	200.0μ A – 200.0mA	0.1μA	±(1.8% 8 Digits)
Resistance	200.0Ω – 20MΩ	0.1Ω	±(1.2% 3 Digits)
Overrange Indication	Yes	>7.5MΩ VDC & >7.5MΩ VAC
AC Bandwidth	50Hz-60Hz
Continuity	Yes
Diode Test	Yes
Digital Display	2000
Lan Tester	RJ45 and RJ11 BNC
Min Max	Yes
Back Light	Yes
Enclosure	Rubber Holster
Batteries	2 x AAA and 9V
Weight	308g
Dimensions	162 x 74 x 43mm
Safety Specs	IEC61010-1 CAT III 600V
