This series offers an easy way to upgrade from a basic mechanical time switch to an electronic time switch. These timers will allow for up-to-the-minute programming, battery backup for power loss, up to 28 events total, and automatic daylight saving time corrections without the need of user interaction. They come in standard 7-day astronomic versions.

Features:

Selector switch to determine input voltage between 120-277 VAC
Up to 28 events total
To-the-minute accuracy
Temporary override or permanent manual override
Automatic Daylight Saving Time adjustment
Astronomic models enable dusk-to-dawn scheduling

Specifications:

Manufacturer: Intermatic
Manufacturer Part Number: ET8015C
Product Type: Electronic Control
Voltage Rating: 120-277 VAC
Frequency Rating: 50/60 Hz
Voltage Selection Type: Selector Switch
Electronic Ballast Load Ratings (NO) Range: 1 A, 120-277 VAC
Inductive Load Ratings (NO) Range: 30 A, 120/240 VAC
Magnetic Ballast (NO) Range: 20 A, 120-277 VAC
Resistive (NO) Range: 20 A, 28 VDC; 30 A, 120/240 VAC
Motor Load Ratings (NO) Range: 1 HP, 120 VAC; 2 HP, 240 VAC
Inductive Load Ratings (NO) Range: 30 A, 120/240 VAC
Knockout Dimensions Back (1) Combination: 1/2" - 3/4"
Knockout Dimensions Bottom (2) Combination: 1/2" - 3/4"
Minimum Wire Size: #14 AWG
Maximum Wire Size: #8 AWG
Number Of Circuits: 1
Switch Type: SPST
Operation Mode: 7 Day
Operating Temperature Range: -40 to 104 Degrees F
Enclosure Type: Indoor Type 1 Metal
Dimensions: 5.55" x 8.3" x 3.25"
Weight: 2.81 lb.
